A couple of months ago my friend and Blogger G3XBM was into buying Pixie kits from China, he thought he had bought a bargain for the £7.00 he paid for the kit?  Shortly afterwards I found the kits at around a couple of Pounds lower than Roger had bought his for. But this was short lived, a week or so later Roger blogged that Andy Cutland had found them for £3.19 pence, this undercut my price yet again by nearly £1.50!!

Well the story continues!! I have now found the Pixie kits cheaper yet again!!! The complete kit as above (inc PCB components and Xtal), all for a penny pinching £2.89p ($4.30 US), and the more you buy the cheaper it gets! Oh yes I forgot the price "Includes" shipping!!

You could buy several kits without busting the bank, and put them on different Bands with Xtal and small mod of low pass filter changes.

Is this now the cheapest Transceiver kit  in the world, or can anyone find them cheaper still??






The normal good old British early Spring wet weather, had stopped any Sunday outside activity, even the cat was having non of it, she was well tucked up after her lunch. Nothing interested me on the television, a boring afternoon ahead or maybe a sleep in the chair?





I remembered there were 2 years worth of Practical Wireless magazines and a few Sprats scattered over the house. 14 were together, 2 were stuck in a drawer by the bed, and the rest were eventually found mixed up with several other piles of junk, which had been dumped together when the XYL had been on one of her recent mad cleaning rounds.







Someone had got me the binders for a present last year, again they took a bit of searching for? But I eventually found them, and set to work. After an hour or so, all were now together sorted and bound, ready for the bookshelf a real professional job!








I like to keep my magazines bound together, making quick reference easy when I want to go back to an article. Todays effort will help with a bulk of projects on the list which you will hear about in the future .

Yesterday evening I received an email from Martin Lynch & Sons that they had despatched a package to me. I was a bit puzzled at first, as earlier in the week I had received my early birthday present I had ordered a day or so before, so I couldn't work out what the package would be, perhaps they had made a mistake?

Then I remembered, I had entered the ML&S guess the Caption competition on their Facebook page. A quick surf over there and I found I had won a Kenwood hand towel, which arrived promptly in this mornings post:



I certainly won't be using it on my face, it will be put on the wall in the soon to be refurbished shack.

If you want to keep up with the top deals and offers at ML&S, join in by liking their Facebook page, it is well worth keeping your eye on!

The FREE multimode digital software package that many have used for years with Windows and Linux, has now been ported to Android. Again available without any restrictions!

Download the APK file, manual, and other details from here.

The software seems to cover many of the same functions, and modes, as its big brother Windows version.


I have only had a short time to play around with this tonight, but soon after I downloaded the APK on to my phone, a quick easy configure it was up and running within 5 minutes.






This now opens the door to cheap home and portable operation, using FLDIGI's modes likes PSK31 etc. Using simple Android tablets and Android PCs available from the likes of ebay for less than £50!

My 7" Android PC below, which should be suitable for use with FLDIGI.







A refurbishment of the shack is long overdue, and some advanced birthday money prompted me to take up one of ML&S recent deals. I had been looking at various Linear power supplies to feed the new layout, and the MP-304mkII would fit the requirement of servicing the array of rigs I have to feed.



Ordering was quick which I did over over the phone,  as normal with Martin Lynch & Sons, the faultless delivery was on time! Infact so quick! I had forgotten to tell the XYL, so she was surprised by the delivery.

The MP304 is sold as a 30A supply, that does 15A continuous, and 20A for 15minutes @13.8V. Supplied with a mains voltage of 230V 50Hz.

There are various output connections on the front, including a handy Cigar lighter socket that can supply 10A.

The supply is variable by an adjustable pot on the front panel, which is biased in the middle of its range to set the supply at the nominal 13.8V. The output is adjustable between 1.5V & 15V DC. With a sliding scale of V/I) (Don't expect 15A Max at 5V as this works out at about 7A)

The large easy to read analogue Meter is switchable either to Volts or Amps.

Supply regulation is better than 1% and a noise figure <10mV is quoted.

We will see how this performs when I will load it up and do a few measurements in the next day or so.

A short form manual is supplied, a circuit diagram would of been useful for servicing in the future. (I have not seen one on the web?)

First looks are good, and not bad for the money of £99!

                                                   Visit to G-QRP Rishworth 2012.

So far it is the only Amateur Radio video I have made. I find I can write about this stuff, quicker and better than I can make video's. However I have not ruled out future output if I find something decent to record and I have the time to edit the footage.




For now I will leave it to the likes of VK3YE and  K7AGE etc, both who output some great "updated" interesting Video's over a wide area of various Ham Radio subjects.

Quiet correct Helen! But not the type you were thinking about, that live with the Elves down the bottom of the garden?

I got involved in this one with G3XBM recently, when he had ordered a kit from a different dealer at a slightly higher price, I was determined to get the price down by using various search method tricks I have come to learn over the years.

The kit(s) arrived from China, within 10 days of ordering. The PCB quality for the kit is excellent! Included is all the components, One Crystal (7.023MHz), and even the schematic and component list were supplied from this ebay dealer. All for a penny pinching £4.70p at the time I ordered!  * Note the price has increased slightly to £5.20p ($8 US) as I write this. This does ask the question though, is this the worlds cheapest transceiver kit including delivery?





I intend to do a couple of mods to my Pixie as I build it, I will replace the 47K preset with a 47K Variable Pot so I can have a couple of KHz Frequency swing or pull to hand when I mount it inside a case. I will also switch in a couple more Crystals 7.030 & 7.040MHz so I can have a bigger spread of the 7MHz CW Band to work with..


The Pixie transceiver has a lot of history too its name, and various mods and developments have been done over the years. If you want the full facts, grab a copy of The_Sprat_Pixie_File from the G-QRP Club Website.

Think about joining the G-QRP club while you are there, as this club is well worthy of joining!

For those who are after full circuit details etc for the Chinese version of this kit try this link here.
