My first rig the Yaesu FT-857D has proved a more than capable radio and as a shack in a box covering HF-VHF-UHF it is excellent and has allowed me to try my hand at most things since becoming licensed but I wanted a dedicated HF set up that was a bit less fiddly to use.

So last month I succumbed to temptation and ordered a Yaesu FT-450D. While it is still an entry level rig I had heard good things about it and liked the look and feel of it. Martin Lynch & Sons had them at a low price and combined with Yaesu's 'Late Winter Warmer 2015' cash-back promotion made it an opportunity I didn't want to miss.

It arrived last week but I only got to properly have a play this weekend even then not for as long as I really would have wanted. I know people might detest HF contests but I was quite glad of the CQ WPX to try out the radio with plenty of contacts on 10/15/20 and 40m while keeping the output below 50W.

I have still to work out all the settings and the DSP functions but first impressions are of an excellent receiver with good tone and clear audio from the internal speaker. Being a very popular contest the bands were crowded at the weekend but I had no trouble picking out weaker stations even with very strong adjacent stations. Using the supplied microphone and the default processing settings I had no issue getting out either, working nearly all of the stations I called.

I have previously used a manual ATU and found the internal ATU is a nice feature when switching bands and it did a excellent job of fine tuning the M0CVO OCFD. It couldn't tune it on 40m directly as the VSWR was greater than 3:1 so had to revert back to the external ATU.

Only very minor gripe I had was the CAT connection, In my research I noted it was a standard RS232C 9-pin connector and assumed I would just plug in a standard PC serial lead, but I hadn't spotted the radio had a male connector not female!

I wanted to try out the CAT but hadn't got a gender changer or connectors in the shack to make up a lead. I did have a number of commercial RS232 extension leads moulded male connector one end, female the other, so chopped up two and spliced the appropriate halves together. It works fine with a USB-Serial adapter in Ham Radio Deluxe but refused to work with the Omnirig control used by PZTLog until I disabled the hardware handshaking.

Still early days and I do need to read the manual but more than happy with it.

I didn’t pay much attention to the GT-1 because I assumed it was just old wine in a new bottle. Time to rectify this, due to popular demand.

We all know the Baofeng BF-666S / BF-777S / BF-888S radios: 16 UHF channels, no display, low power output, a receiver which can be overloaded by snapping your fingers, but they are dirt cheap. The GT-1, co-developed by SainSonic, promises to improve on this concept by adding FM radio, a higher capacity battery and higher power output.

Look & feel
When it comes to looks, the GT-1 looks a bit more modern than its predecessors. The radio is slightly taller and less deep. All in all the GT-1 looks and feels nice. The basic concept didn’t change: 16 programmable UHF channels between 400 MHz and 470 MHz, scramble (voice inversion), a on/off/volume pot, a 16-step rotary encoder and a flashlight. Apart from emitting a steady beam of light the flashlight now offers an ‘SOS- mode: three short, three long and three short pulses.

You can order the radio with side keys in different colors: yellow, orange or green. The (of reasonable quality) manual comes in three languages: English, French and German. Nice touch.

Battery
According to the specs printed on the battery the nominal voltage is 7.4 Volts @ 1800 mAh, the same capacity as the UV-5R battery.  Such a capacity would be in line with the higher power output promised on the radio label: a solid 5 Watts instead of ‘less or equal to 5 Watts’ printed on a BF-888S (which proved to be 2 Watts only).

The first hint of something being terribly wrong was the weight of the battery. It felt so light that I was afraid that it might end up at the other end of the living room if I had a nasty cough. Time to to take a closer look at things. Let’s take a look at the weight first as more cells always translates into a heavier battery.  The amount of plastic used plays a role too, of course. So while this is not a 100% reliable method, it does give you an indication.

Battery weight comparison
Pofung GT-1: 47 grams
Baofeng BF-666S: 54 grams
Baofeng UV-5R: 80 grams
Anytone NSTIG-8R: 96 grams

As you can see the weight of the GT-1 and BF-666S batteries are close. The UV-5R and NSTIG-8R batteries are too, both proven to be 7.4 Volts @ 1800 mAh. The GT-1 battery seems just too light to be in the same 7.4 Volts / 1800 mAh league.

I took my multimeter and checked the GT-1 battery. Not to my surprise it only measured 4.0 Volts (freshly charged), so the nominal voltage is 3.7 Volts only, just like the BF-666S battery. The capacity will likely be the same too, somewhere between 1000 mAh and 1500 mAh.

Transmitter
After finding out that the battery might even be inferior to the one supplied with its predecessor I didn’t expect the GT-1 to be able to reach 5 Watts output at all. That proved to be correct. Two samples measured the same: between 1.5 – 2 Watts, depending on the frequency.

TX Audio
A bit brighter and slightly louder than my BF series, which is a plus.

Phase noise and harmonics
Less phase noise than the BF series. There are some unusual peaks visible, but nothing scary.

Receiver
At -126 dBm the GT-1 is sensitive enough, but that won’t help you much. It doesn’t take much of an out-of-band signal to make the radio as deaf as a post. Even the local repeater can’t be received in my city center; only if I’m about 3 kilometers away from the center the receiver comes to life.

FM Radio
By holding the upper side key while switching on the radio, the GT-1 will switch to FM radio, something the BF series don’t offer. There doesn’t appear to be a way to tune to a preferred station though; it randomly tunes into stations it finds. This makes the feature of limited use.

Edit: pressing the upper side key shortly will make the radio switch from station to station. Some in-house interference made the system fail when I tested it. The interference caused the scan to stop when encountering these false positives.

RX Audio
A bit raw, just like with the BF series, but more tinny. Audio distorts quickly if you crank up the volume.

Software
The GT-1 can be programmed with the same software developed for the BF series. CHIRP works too, but lacks a few options such as switching on scramble. Changing power output from ‘High’ to ‘Low’ in the software still doesn’t work; the radio just ignores that setting.

The verdict
After being confronted with all the lies surrounding the Pofung GT-1 there’s no way I can justify a diplomatic way of saying things. The GT-1 is just old wine in a new bottle, the battery voltage / capacity is one big lie and so is the promised power output.

The receiver is still disappointing unless you live in the proverbial ‘middle of nowhere’. To make matters worse the GT-1 is more expensive than a Baofeng BF-666S / BF-777S / BF-888S.

In short: don’t buy one unless you’re a notorious masochist. Go for a UV-5R instead or, if you like/need this particular concept, buy the superior Anytone ANILE-8R.

I didn’t pay much attention to the GT-1 because I assumed it was just old wine in a new bottle. Time to rectify this, due to popular demand.

We all know the Baofeng BF-666S / BF-777S / BF-888S radios: 16 UHF channels, no display, low power output, a receiver which can be overloaded by snapping your fingers, but they are dirt cheap. The GT-1, co-developed by SainSonic, promises to improve on this concept by adding FM radio, a higher capacity battery and higher power output.

Look & feel
When it comes to looks, the GT-1 looks a bit more modern than its predecessors. The radio is slightly taller and less deep. All in all the GT-1 looks and feels nice. The basic concept didn’t change: 16 programmable UHF channels between 400 MHz and 470 MHz, scramble (voice inversion), a on/off/volume pot, a 16-step rotary encoder and a flashlight. Apart from emitting a steady beam of light the flashlight now offers an ‘SOS- mode: three short, three long and three short pulses.

You can order the radio with side keys in different colors: yellow, orange or green. The (of reasonable quality) manual comes in three languages: English, French and German. Nice touch.

Battery
According to the specs printed on the battery the nominal voltage is 7.4 Volts @ 1800 mAh, the same capacity as the UV-5R battery.  Such a capacity would be in line with the higher power output promised on the radio label: a solid 5 Watts instead of ‘less or equal to 5 Watts’ printed on a BF-888S (which proved to be 2 Watts only).

The first hint of something being terribly wrong was the weight of the battery. It felt so light that I was afraid that it might end up at the other end of the living room if I had a nasty cough. Time to to take a closer look at things. Let’s take a look at the weight first as more cells always translates into a heavier battery.  The amount of plastic used plays a role too, of course. So while this is not a 100% reliable method, it does give you an indication.

Battery weight comparison
Pofung GT-1: 47 grams
Baofeng BF-666S: 54 grams
Baofeng UV-5R: 80 grams
Anytone NSTIG-8R: 96 grams

As you can see the weight of the GT-1 and BF-666S batteries are close. The UV-5R and NSTIG-8R batteries are too, both proven to be 7.4 Volts @ 1800 mAh. The GT-1 battery seems just too light to be in the same 7.4 Volts / 1800 mAh league.

I took my multimeter and checked the GT-1 battery. Not to my surprise it only measured 4.0 Volts (freshly charged), so the nominal voltage is 3.7 Volts only, just like the BF-666S battery. The capacity will likely be the same too, somewhere between 1000 mAh and 1500 mAh.

Transmitter
After finding out that the battery might even be inferior to the one supplied with its predecessor I didn’t expect the GT-1 to be able to reach 5 Watts output at all. That proved to be correct. Two samples measured the same: between 1.5 – 2 Watts, depending on the frequency.

TX Audio
A bit brighter and slightly louder than my BF series, which is a plus.

Phase noise and harmonics
Less phase noise than the BF series. There are some unusual peaks visible, but nothing scary.

Receiver
At -126 dBm the GT-1 is sensitive enough, but that won’t help you much. It doesn’t take much of an out-of-band signal to make the radio as deaf as a post. Even the local repeater can’t be received in my city center; only if I’m about 3 kilometers away from the center the receiver comes to life.

FM Radio
By holding the upper side key while switching on the radio, the GT-1 will switch to FM radio, something the BF series don’t offer. There doesn’t appear to to be a way to tune to a preferred station though; it randomly tunes into stations it finds. This makes the feature of limited use.

RX Audio
A bit raw, just like with the BF series, but more tinny. Audio distorts quickly if you crank up the volume.

Software
The GT-1 can be programmed with the same software developed for the BF series. CHIRP works too, but lacks a few options such as switching on scramble. Changing power output from ‘High’ to ‘Low’ in the software still doesn’t work; the radio just ignores that setting.

The verdict
After being confronted with all the lies surrounding the Pofung GT-1 there’s no way I can justify a diplomatic way of saying things. The GT-1 is just old wine in a new bottle, the battery voltage / capacity is one big lie and so is the promised power output.

The receiver is still disappointing unless you live in the proverbial ‘middle of nowhere’. To make matters worse the GT-1 is more expensive than a Baofeng BF-666S / BF-777S / BF-888S.

In short: don’t buy one unless you’re a notorious masochist. Go for a UV-5R instead or, if you like/need this particular concept, buy the superior Anytone ANILE-8R.



Living in New Jersey makes filling the requirements of this theme a snap!

Right off the bat, I'm thinking that I could go to Johnson Park in either Highland Park or New Brunswick and operate right on the banks of the Raritan River, which according to Wikipedia:

"The river has served an important water transportation route since the Pre-Columbian era. The name Raritan is also applied to the Raritan people, an Algonquian tribe that inhabited Staten Island, near the river's mouth."

Or perhaps I could go over to Piscataway Township and operate from there:

"The name Piscataway may stem from the area's original Native American residents, transplants from near the Piscataqua River defining the coastal border between New Hampshire and Maine, whose name derives from peske (branch) and tegwe (tidal river),^[18] or alternatively from pisgeu (meaning "dark night") and awa ("Place of")^[19] or from a Lenape language word meaning "Great Deer".

Or, I could even go to one of my favorite spots, Washington Rock State Park, as it is on the first ridge of the Watchung Mountains, which according to Wikipedia (again):

"The original inhabitants of the Watchungs, the Lenape, referred to the mountains as the Wach Unks, or ‘high hills’.^[9][10] Evidence of the Lenape presence in the Watchungs can be seen in numerous camps sites that have been uncovered, mainly along the rivers coursing through mountains and in the small caves abundant in the volcanic rock. It is thought the Lenape favored the Watchungs for their profusion of natural resources, including abundant freshwater rivers and streams, a variety of forests, and plentiful fish and game.^[11] They also took advantage of the rich soils and maintained many farm areas where they raised a variety of seasonal crops."

So I have plenty of places to choose from. Sometimes the themes that Paul comes up with can be somewhat of a challenge - for example, last year's "Cinco de Mayo" theme. There's not much in New Jersey that has a true Mexican connection.

This year's theme is pretty easy to comply with.

72 de Larry W2LJ
QRP - When you care to send the very least!

It's raining outside, so I haven't gone to the Jeep for any lunch time QRP. In fact, I didn't bring the radio with me at all today. Yes, I will confess, I am a bit of a weather wimp. I hate setting up antennas (yes, even the Buddistick, which is a snap) this time of the year in the rain. Not a big issue for me in the late Spring or Summer, when it's warm. But when it's raining this time of year, it just feels raw - colder than it is, even if it's a bit warmer than it has been.

So I've been spending my lunch hour writing this post and Googling "Field Day Wire Antennas". Last year's EARCHI EFHW (Emergency Amateur Radio Communications Hawaii End Fed Half Wave) and G5RV both worked well, and more than likely, we are going to use them again. However, we have decided to add a digital station and a GOTA station, so we need to come up with two more wire configurations.

The digital station will be W2OU's FT-817 and I believe we are using KD2FSI's FT-897. Both W2OU and I have PAR END-FEDZ 10/20/40 antennas. While easy to deploy and use, they would prohibit us from getting on 80 Meters and 15 Meters. I am considering as possibilities, the G7FEK or perhaps the D3+ antenna. Both seem somewhat easy to construct.  As the weather gets warmer, I may have to build one of each and then take them to the local park to see (in reality) how easy they are to set up and what kind of results I can garner.

K2VHW has a few disassembled multi band yagis in his garage. If he can determine that he has all the pieces and parts, we broached the concept of perhaps deploying one using an extension ladder as a "tower". That would make life a little easier for the QRP SSB guys.

My goal is to keep things as simple as possible while still allowing us to get credible results. After being out in the field for 24+ hours (if you include set up), no one really wants to face the prospect of spending an enormous amount of time tearing everything apart.  Come 2:00 PM on Field Day Sunday, my mind is more on a good meal and a hot shower than worrying about packing and stowing.

We have ample time yet, so more investigation seems likely.  Now if only I can find my copy of Bill Orr's "Simple Wire Antennas". That would help immensely!

72 de Larry W2LJ
QRP - When you care to send the very least!

Firstly my apologies, last weeks post about the Eggciting Eggsplorer-1 HAB project and the talk and demonstration on SSDV wasn't posted on Amateurradio.com due to an error.

This week South Kesteven ARS (SKARS) held an EGM where I was voted on as the new Chairman. Nigel Booth M0CVO has stepped down following four years in the position citing increasing business commitments. Nigel intends to remain an active member, I and the other members wish to thank Nigel for his efforts over the years and wish him well with his business ventures.

SKARS has a small membership at present which we hope to increase but the committee finds itself in the  Catch-22 position of not having a lot of funds in order to put on activities and promote ourselves to increase the membership.

I have created a social media presence in the form of a Facebook page and twitter account in addition to updating the societies web page.I am hoping that permission willing the GB2EGG and Eggsplorer-1 project will significantly promote the society and the hobby.

I know running a club/society isn't a trivial undertaking, especially if working full time having chaired a large dog agility training club many years ago. It can take a lot of effort and time and it can sometimes be a thankless task.

Indeed my first twenty-four hours has Chairman saw my first sacrifice, a lovely Yaesu FT-450D was delivered yesterday and I have yet to take it out of the box!


Something to be remedied this evening.

I have a new high altitude balloon project, this one is very Eggciting.

In June my club South Kesteven Amateur Radio Society (SKARS) will be operating a special event station at the Swaton Vintage Day held at Thorpe Latimer in Lincolnshire.

The 2015 Swaton Vintage Day will also host the 10th World Egg Throwing Championship  and in recognition the special event station will have the call sign GB2EGG. This popular annual show raises money for local, national and international good causes.

Egg Throwing is recognised by the English Sports Council and the sport is taken very seriously by some competitors. Hundreds of competitors from Europe and around the world are expected to compete this year. Last year’s event attracted teams from Germany, Slovenia, Hong Kong and Brazil.

While planning the special event station I jokingly suggested throwing an egg in to space on board a balloon, I shouldn't have yoked as it is now a serious project. The idea coming from Dave Akerman's Spudnik flight for Heston Blumenthal’s Channel4 television program.

Image with the permission of Dave Akerman

Subject to Civil Aviation Authority clearance and weather conditions I will hopefully launch a high altitude balloon carrying one lucky egg into the edge of space and then dropping it back to earth under a parachute. In addition to the plucky Eggstronaut the balloon I have called Eggsplorer-1 will carry a radio transmitter to broadcast its position, altitude and live images of the journey back to earth.

On board cameras will record the journey to be recovered on a successful return to Earth. Radio enthusiasts all around the country will be able to assist receiving the data and pictures and track the progress of the flight via the UK High Altitude Society tracking website.

More details and progress will be posted on here and on the Eggsplorer-1 website  and you can follow developments on twitter @eggsplorer1South Kesteven ARS welcomes anybody with an interest in radio communications, so if want to be involved in this and other events like this please visit us at the show or visit the South Kestevan ARS website and on twitter @M0SKR

I have already begun development of the payload, unlike the moth-balled NERD-1 payload this one will use one of the Raspberry Pi boards since I want to transmit SSDV images live and it supports its own specially designed camera modules. NERD-1 will still fly as a backup tracker.

Dave Akerman (M0RPI) and Anthony Stirk (M0UPU) have developed the Pi-In-The-Sky ready made boards and the design and software are open-sourced, using this as a starting point together with Phil Heron's (MI0VIM) SSDV software I quickly had a prototype dubbed NERDPI running.


I did have an issue since the GPS module I currently have only outputs serial data so had to use one of those small TTL USB-Serial adapters and spun some of my own code to get the data out and was soon successfully decoding my own transmissions from the shack and uploading them to the Habhub system.


Today has seen the spectacular partial solar eclipse here in the UK, during the eclipse several HAB flights were launched to try to capture images above any cloud cover (details here)  Fellow SKARS members and members from the Grantham ARC were keen to decode the SSDV images themselves as the BBC Stargazing Live balloons were flying from nearby Leicester.

So on Wednesday I did a talk and demonstration to show how to track and decode the images, it was well received and I uploaded pictures of the audience to the system.


Unfortunately technical issues prevented live images from the Stargazing HABs being transmitted but I was able to decode some images from the University of Southampton OLAF payload They were only lo-res but still pleased to get decodes here it was a good distance from me.

Here in Newark the sky was beautifully clear so the eclipse was visible and spectacular, where OLAF was flying was covered in cloud, so the mission was a success.
