MW DXer, John Bellini in Colorado, has recently posted another interesting set of YouTube videos describing the mechanical construction and operation of his cool, and somewhat stealthy, Low Noise Vertical (LNV) as well as his phaser in action against some IBOC and local blowtorch signals.

  His use of the phaser is particulary interesting. Here he demonstrates what two LNV's can do when phased correctly. The second antenna being used is one of his wire LNV's located further back in the yard.

The first video shows phasing against local IBOC crud.



The second video shows the phaser in use to knock down the sideband hash from a strong local (KOA) signal, 25 miles away.


For those that like to DX in real time (unlike those using SDR overnight samplings), the phaser has much to offer.

The one being used in the videos is the Quantum Phaser and more information about it may be found here.

More on phasers next time.

One CLE Target - 'VR'  266KHz / Vancouver Int'l Approach

How time flies. For you low-frequency buffs, another challenge awaits. From CLE coordinator Brian Keyte (G3SIA) comes the following reminder:




"Our February Co-ordinated Listening Event will soon be here.
We'll be hunting for normal beacons in two contrasting frequency ranges.
One range also gives the possibility of hearing several amateur beacons.
As always, first-time CLE logs will be extra welcome.

Days: Friday 20 February - Monday 23 February
Times: Start and end at midday, your local time
Frequencies: 260.0 - 269.9 kHz
plus: 440.0 - 1740.0 kHz

Many of us should be able to hear beacons in both ranges, though Europe
only has a handful in the '260s'. From 440 onwards, Eastern Europe and
North Africa have several beacons and some regular UNIDs and some NDBs
can be found among Europe's Medium Wave Broadcast Stations.

Many of us are within range of some of the amateur beacons on frequencies around 470 kHz and 500 kHz - we'll be listening for ANYTHING OPERATING IN BEACON MODE, preferably with normal speed Morse.
(We ask operators who sometimes use QRSS, PSK, WSPR, etc., which need
software to receive them, to PLEASE CHOOSE THE SIMPLER MODE during
the CLE so that we shall all be able to receive and report them).

Send your CLE log to the List, preferably as a plain text email
and not in an attachment, with CLE191 at the start of its title.
Please show on EVERY LINE of your log:

# The full Date (or Day no.) and UTC (the day changes at 00:00 UTC).
# kHz (the beacon's nominal published frequency, if you know it)
# The Call Ident.

Other optional details, Location, Distance, etc., go LATER in the same
line (or in footnotes). Any extra details about UNIDs, especially strong
ones that may be near to you (maybe their approximate direction, etc.)
will help us to discover more about them. As always, please make your
log useful to old and new members alike by including your own location
and brief details of the equipment and aerial(s) you were using.

I will send an 'Any More Logs?' email at about 18:00 UTC on Tuesday
evening. From it you can check that your log has been found OK.
Do make sure that your log has arrived at the very latest by 09:00 UTC
on Wednesday 25 February.
I hope to finish making the combined results on that day."


These listening events serve several purposes. They:

• determine, worldwide, which beacons are actually in service and on-the-air so the online database can be kept up-to-date

• determine, worldwide, which beacons are out-of-service or have gone silent since the last CLE covering this range

• will indicate the state of propagation conditions at the various participant locations

• will give you an indication of how well your LF/MF receiving system is working

• give participants a fun yet challenging activity to keep their listening skills honed

Final details can be found at the NDB List website, and worldwide results, for every participant, will be posted there a few days after the event. If you are a member of the ndblist Group, results will also be e-mailed and posted there.

The very active Yahoo ndblist Group is a great place to learn more about the 'Art of NDB DXing' or to meet other listeners in your region. There is a lot of good information available there and new members are always very welcome.

If you are contemplating getting started on 630m, listening for NDBs  is an excellent way to test out your receive capabilities as there are several NDBs located near this part of the spectrum.

You need not be an ndblist member to participate in the CLEs and all reports, no matter how small, are of much value to the organizers. 'First-time' logs are always VERY welcome!

Reports may be sent to the ndblist or e-mailed to either myself or CLE co- ordinator, Brian Keyte (G3SIA), whose address appears above.

Please...do give the CLE a try....then let us know what NDB's can be heard from your location! Your report can then be added to the worldwide database to help keep it up-to-date.

Just a reminder about the 630m crossband activity night this evening. There have been two updates to the plan. VE7SL will start one hour later than originally planned and John, VE7BDQ, will be listening on both 160m and 80m QSX frequencies for callers.

The frequencies will be:

• VE7SL TX 473.00KHz QSX (listening) 1808KHz (160m) and 3535KHz (80m)

• VE7BDQ TX 474.00KHz QSX (listening) 1813KHz (160m) and 3532KHz (80m)

John will operate from 0200Z (1800 PST) - 0700Z (2300 PST) while I will start one hour later. Both stations will call several CQs at the top of each hour segment, at full eirp,  and listen for any callers on the specified calling frequencies.




The last time this was done, transcontinental contacts were completed ... hopefully conditions will continue to co-operate and propagation will be good tonight.

I'm the chap who looks after our monthly Co-ordinated Listening Events (CLEs).

About 70 of our NDB List members have taken part in recent CLEs - and the other 550 members haven't. Only about 250 members have ever sent a CLE log (including all ex-members), so more than 300 current members haven't.

If you are one of the 300+, do you sometimes look at our monthly CLE results and maybe find bits of them interesting or useful?

This is NOT a sales pitch to try and make you take part, welcome though that would be! However, if several 'non-CLE' Members are finding the results helpful, I would like to know whether we might improve the way the results are presented to make them more understandable and more useful to our members generally?

If you are interested, it would help me if you could please reply DIRECT TO ME at [email protected]



I will keep your reply confidential and I will try to acknowledge all replies individually - there may be just yours or there might be 100 of them !!


1. How often have you found any individual listener's CLE log of interest?


2. How often have you looked at any of the CLE combined results?

Once or twice
Sometimes
Often

3. (if any) Which results were of interest?

Tables, etc. in the Excel attachments
Tables, etc. in the CLE Archives


4. Did you find that the results needed further explanation?

Yes, sometimes
Yes, often
Yes, always






6. Have you sent your own listening log(s) to NDB List?


7. Finally, please confirm that you are one of the 300+

I've only sent 1 or 2 CLE logs




Brian Keyte

(CLE Co-ordinator)

YJ-200KHz - Victoria Int'l

Listeners towards the central and southern portions of North America reported phenomenally good conditions this weekend, most unusual for a CLE event! Out west and here in BC, conditions were not noticeably enhanced and could best be described as kind of 'mushy' ... most signals were a struggle. The further south you went, the better the propagation became.

CFL Crud

Unfortunately, I am still struggling with noise pollution (cheap or failing CFLs) in a house about ten properties away, creating a constant 60 Hz hum and drifting birdies throughout the band ... as it was during the last CLE. Hopefully the owners of the home will return before the next CLE arrives!

25 04:00  198      DIW       Dixon, NC, USA
24 06:00  200     YJ          Victoria - Sidney Island, BC, CAN
24 04:00  200     YDL       Dease Lake, BC, CAN
25 07:00  200     UAB       Anahim Lake, BC, CAN
24 04:00  201     ZWN      Winnipeg, MB, CAN
24 12:00  201      IP           Lufthansa, AZ, USA
24 07:00  201      GV         Greenville, TX, USA
26 05:40  201      YVZ      Deer Lake, ON, CA
24 06:00  203     ZKI        Kitimat, BC, CAN
24 06:00  203     YBL       Campbell River, BC, CAN
24 06:00  203     TCY       Tracy Municipal Apt, CA, USA
24 04:00  204     ZQR       Regina, SK, CAN
24 11:00   205      XZ          Wawa, ON, CAN
24 04:00  205     COR      Corcoran, CA, USA
24 04:00  206     SOW      Show Low Regional Apt, AZ, USA
24 04:00  206     EF          Castlegar, BC, CAN
24 04:00  207     YNE        Norway House, MB, CAN
24 04:00  207     PY          Fort Chipewyan, AB, CAN
24 07:00  209     ITR         Burlington, CO, USA
24 04:00  209     IB            Atikokan, ON, CAN
25 14:00   209     HGT       Tusi AHP, CA, USA
24 04:00  209     CYT        Yakataga Apt, ALS
24 04:00  211     HDG       Gooding, ID, USA
24 04:00  212     YGX        Gillam, MB, CAN
25 04:00  212     MPZ        Mount Pleasant, IA, USA
24 04:00  212     CGL        Juneau, ALS
24 07:00  212     CFV        Coffeyville, KS, USA
24 04:00  214     LU           Abbotsford, BC, CAN
24 04:00  215     ZAB         Edmonton (Intl Apt), AB, CAN
24 11:00   215     TQH        Tahlequah, OK, USA
24 04:00  216     GRF        Fort Lewis, WA, USA
24 04:00  216     CLB        Wilmington, NC, USA
24 04:00  217     EC           Enoch, UT, USA
24 11:00   218      RL           Red Lake, ON, CAN
24 04:00  218     PR           Prince Rupert, BC, CAN
24 04:00  219     ZRS         Regina, SK, CAN
24 07:00  220     HLE         Hailey, ID, USA
24 04:00  221     QU          Grande Prairie, AB, CAN
24 04:00  222     WY          Wrigley, NT, CAN
24 04:00  223     YKA        Kamloops, BC, CAN
24 04:00  223     AFE         Kake Apt, ALS
25 11:00   224      MO          Moosonee, ON, CAN
24 04:00  224     DN          Dauphin, MB, CAN
25 04:00  225     X5           Vegreville, AB, CAN
24 04:00  225     LWG       Lewisburg - Corvallis, OR, USA
25 04:00  227     YAC        Cat Lake, ON, CAN
25 12:00   227     MHM       Minchumina, ALS
24 04:00  227     CG           Castlegar, BC, CAN
24 04:00  229     AKW       Klawock, ALS
24 06:00  230     YD           Smithers, BC, CAN
24 07:00  230     VG          Vermilion, AB, CAN
24 11:00   230     NRN       Norton, KS, USA
24 07:00  230     BI            Bismarck, ND, USA
24 07:00  233     QN          Nakina, ON, CAN
24 07:00  233     OKS       Oshkosh, NE, USA
25 14:00   233     LG          Seal Beach, CA, USA
24 04:00  233     BWP       Breckenridge, ND, USA
24 04:00  233     BR          Brandon, MB, CAN
25 12:00   233     AZN        Amazon, MO, USA
24 04:00  233     ALJ         Hinchinbrook Island, ALS
25 04:00  235     CN         Cochrane, ON, CAN
25 04:00  236     ZRJ        Round Lake, ON, CAN
24 04:00  236     YZA       Ashcroft, BC, CAN
24 04:00  236     FOR       Forsyth, MT, USA
24 04:00  238     MPA      Nampa, ID, USA
24 04:00  239     OJ          High Level, AB, CAN
25 04:00  381.5   SJX       St James, MI, USA

Listening for NDBs is a practical way to check out your LF receive capability, should you be interested in developing a good 630m station or in following the nuances of night-to-night MF propagation.

Early morning (Jan 22) saw BCB conditions vastly improved over what they have been for most of the season. Because I am on the wrong (none-Pacific) side of Vancouver Island, as well as on the eastern shores of Mayne Island, I usually don't listen for Asian signals on my Perseus recordings but a quick check of Thursday's recordings revealed some very solid signals from many Japanese stations, as well as Korea. Most signals were strongest at around 1500Z (7 a.m. local) but were first audible from about 1200Z.

Three of the good performers are shown in the video below:

• JOBB  828KHz NHK2 Osaka
• JOAK  594KHz NHK1 Tokyo
• HLAZ 1566KHz Jeju, South Korea / Far Eastern Broadcasting Company

Numerous other signals, reaching similar strengths were audible throughout the broadcast band on their 9KHz-spaced channels. Interestingly, I had configured my LF inverted-L into a temporary version of a low noise vertical (LNV) by removing all of the loading coil and feeding with an isolating impedance matching transformer. I rather suspect that in this mode it is acting as a normal quarter-wave inverted-L however as its self-resonant frequency, without any loading, is around 1200KHz. Today's conditions were much poorer but several Asian signals were heard once again.

Should conditions improve, the next time I will use my large loop oriented to favor Japan and also take advantage of its ability to null many of the local blowtorch signals from Vancouver, off to the side.

There's been a lot of discussion lately on the Yahoo Groups ndblist regarding the "low-noise vertical" (LNV) and it's seemingly excellent performance. Originally described by Dallas Lankford as a good performer from LF to SW, ndblist member, Phil (KO6BB), recently refurbished his earlier built 'LNV', but this time with better feedline and appropriate ferrite cores for the antenna's matching transformers. Some of his description appears below.


To recap. I put the LNV up last spring to overcome the bad IMD products
from local BCB stations I was seeing in the LF region when using the
Roelof Active Whip located about 36 feet AGL. The low noise vertical is
... about 30 feet of antenna, set at roof-line level in this mobile home. As I wasn't sure how well the antenna would perform, I first made it a "Zero Dollar" project, using items I had on hand. Those items included two toroid cores salvaged from a defunct computer PS. I figured that since the supplies operate in the kHz range (as witness what a dirty supply will do to your LF reception), they would be suitable for at least a trial run of the antenna. The balanced feedline was some CAT6 cable I had on hand.

The antenna was a great success, because while it had much lower signal
output than the active whip, it also had ZERO IMD from the BCB stations,
and also less local 'junk' (read noise). The tunable pre-amp I use more
than made up for the lower output of the antenna, after all Signal/Noise
ratio is EVERYTHING in this hobby, NOT how high you can make the "S"
meter read.

The central valley summer heat (often in the 100's) took it's toll on
the CAT6 feedline outer jacket insulation, and while it still seemed to
work OK, I figured that it wouldn't be long before water started to get
into the line and probably degrade it in rainy/foggy weather.

Anyway, I went ahead and ordered the proper toroid coils I needed along
with 25 feet of nice 300 Ohm foam twinlead, and got a couple plastic
boxes to put it all in and made the toroid units. While I was at it ordered
two Amidon FT193-J toroid cores to complete the LNV the way I REALLY wanted to.

Today I installed it all, putting a heavy twist in the feedline to try
to reduce any stray noise pickup on the balanced feedline. I'd say
probably not likely but why take a chance.

OK, here are the results. I took signal level readings of eight 24/7
stations, both before and after changing out the wiring/baluns. The
bottom line is, the new antenna IS an improvement in the NDB range,
tapering off slightly at the high end of the broadcast band. Yeah, it's
'only' a couple "S" units at it's best, but when you're digging for that
weak NDB even 1 "S" unit is a LOT! I'm going to 'assume' 6dB per "S"
unit as I have calibrated the "S" meter of the R-71A receiver.

NOTE: This is 'fuzzy' math, don't take them as 'exact' on the dB readings.

FREQUENCY BEFORE AFTER DIFFERENCE
203 TCY S2 S4 2 S units (12dB)
205 COT S3 S5 2 S units (12dB?)
344 FCH S9+7 S9+15 (8dB)
374 LV S6 S7 1 S unit (6dB)
580 BCB Sta S9+35 S9+38 (3dB)
770 BCB Sta S9+32 S9+32 No Change
880 BCB Sta S9 S9 No Change
1450 BCB S9+10 S9+5 (-5dB)

SO, it looks like the antenna is definitely an improvement where I'm
REALLY interested in it (the NDB band). I could have probably tailored
the toroids for maximum performance, but just used the 81:9 turns ratio
on the outdoors (antenna) and 9:9 on the indoor unit as I'm FAR too lazy
to run up and down the ladder to remove the toroid box, change turns and
retry it again!!!

Some additional notes.

NOTE 1. I have three ground rods dedicated to just this antenna, two 8
footers and a 4 footer. While I was playing with the antenna taking
readings AFTER the work, I disconnected one of the 8 foot rods to see
what effect that had. Signal levels dropped approximately an "S" unit
across the board. So GOOD grounding on this antenna does make a difference!

NOTE 2. I'm NOT exactly sure why it happened, but after the antenna
work here, there was even LESS "local grunge" in the background than
before, even with the stronger signals, making for even better copy on
weak ones than I otherwise expected. . . It DOESN'T make sense to me,
but then, antennas ARE the magic art.


It appears that the grounding plays some importance in the performance of this "non-resonant" aperiodic antenna and the fact that it is non-resonant on the frequencies of interest likely also plays an important part in its good S/N performance.

Several years ago I noticed something similar. My own 10' tuned air-core loop made an excellent receive antenna on 160m, even though the loop was tuned to around 300KHz! Although signal strength was several S-units below my transmitting antenna, the loop was extremely quiet and weak signals were much easier to copy ... In fact I often heard signals on the mis-tuned loop that I could not hear on my resonant half-sloper radiator.

Another ndblist proponent of the low noise vertical is John, in Colorado, who employs three ... one of them a great-looking tilt-over version. The tilt-over is nicely demonstrated in his short you tube video below.


The antennas are also used in combination via his Quantum Phaser, when DXing the broadcast band. The excellent phasing results can also be seen in his short video, while using a wonderful, like new,  Hammarlund SP-600 JX.


Dallas Lankford's original article may be found here, while an earlier more encompassing discussion will be found here. A third Lankford article, discussing 'Signal To Man Made Noise Ratios' and comparisons of various receiving antennas, also makes for interesting reading.

Perhaps the 'LNV' might be the antenna you're looking for to boost your LF/MW reception.
